2-2 Chapter 2: Setup
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• The recommended adjusting angle is +20˚ to -5˚ (for tilt)/+20˚ to -20˚ (for
swiveling)/ +130 mm (for height adjustment)/90˚ (for portrait view).
130mm
20°
20°
0°
-5°~ +20°
(Swivel)
(Height adjustment)
(Tilt)
It is normal that the monitor slightly shakes while you adjust the viewing angle.
Pivoting the monitor
1. Lift the monitor to the highest position.
2. Tilt the monitor to its maximum angle.
3. Pivot the monitor to the angle you need.
0°
90°
0°
90°
-5°~ +20°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
