ATI Q46 Modbus Communications Manual
13
O&M Manual
Rev-D (2/16)
Detailed status data from registers 30009 and 30010 are detailed in Figure 4 below.
Register
Bitfield
Description
30009
0 (lsb)
mV Hi
1
mV Lo
2
D.O. Hi
3
D.O. Lo
4
Temp Hi
5
Temp Lo
6
NU
7
NU
0
EE Fail
1
NU
2
LCD Controller Fail
3
Cal D.O. Fail
4
PID Controller Fail
5
Cal TC Fail
6
TC Error
7
Acknowledge Fail (global)
30010
0
Alarm 1, Relay A
1
Alarm 2, Relay B
2
Alarm 3, Relay C
3
Alarm 4, Relay D (optional)
4
Alarm 5, Relay E (optional)
5
Alarm 6, Relay F (optional)
6
NU
7
NU
Figure 4 - Status Register Bitfield Flags
