Atlas Copco G 2 User Manual

Reference Designation
1x3 Terminal block of earth protection
1x5 Terminal block of control unit
Electrical diagram
2205 0161 00 Service diagram G 2 – G 3 – G 4 DOL IEC
2205 0161 50 Service diagram G 4 – G 5 – G 7 YD IEC
2205 0347 00 Service diagram G 2 – G 4 – G 5 – G 7 DOL UL
2205 0347 50 Service diagram G 2 – G 4 – G 5 – G 7 DOL CSA
The complete electrical diagram can be found in the electric cubicle.
The complete electrical diagram can be found on the USB supplied with the machine.
2.8 Protection of the compressor
Safety valve on the compressor
Instruction book
2920 7199 10 25
