54
Instruction book
9096 3321 00
(4) Unloading pressure 2
(5) Loading pressure 2
(6) Back
(7) Modify
• The screen shows the actual unloading and loading pressure settings for both pressure bands. To
modify settings, move the cursor to the action button Modify and press the enter key, following screen
appears:
• The first line of the screen, Unloading Pressure 1, is highlighted in red. Use the scroll keys (1) to
highlight the setting to be modified and press the enter key (2). Following screen appears:
• The upper and lower limit of the setting is shown in grey, the actual settings is shown in black. Use
the arrow up or arrow down key of the scroll keys (1) to modify the settings as required and press the
enter key (2).
• If necessary, change the other settings as required in the same way as described above.
