Atlas Copco GA 37+ User Manual

95
Instruction book
9096 3321 00
Reference Designation
1 Electric cable passage
2 Cooling water outlet
3 Cooling water inlet
4 Dryer cooling air outlet
5 Compressor cooling air outlet
6 Compressed air outlet
7 Dryer Cooling air inlet
8 Compressor cooling air inlet
9 Cubicle cooling air inlet
10 Energy recovery inlet
11 Energy recovery outlet
12 Compressed air, dryer bypass outlet
13 Automatic drain, aftercooler
14 Automatic drain, dryer (On Workplace Full-Feature units)
15 Drain,optional DD/PD filter

Atlas Copco GA 37+ Specifications

General

Model	GA 37+
Category	Air Compressor
Motor Power	37 kW
Cooling System	Air-cooled
Drive Type	Direct drive
Working Pressure	7.5-13 bar
Noise Level	69 dB(A)
