Instruction book
4 MAINTENANCE
Attention: Before starting any maintenance, press stop button
O (10-Fig. 1.7), press the emergency stop button (S3-Fig. 1.1),
close the air outlet valve, open manual drain valves (1 and 4-
Fig. 1.5) and switch off the voltage.
The air outlet valve can be locked as follows:
- Close the valve.
- Remove the bolt fixing the handle to the valve.
- Lift the handle and turn it until the slot fits over the blocking
edge.
- Fix the handle to the valve using the special bolt and wrench
delivered loose with the compressor.
Mechanical maintenance
Before starting maintenance, open drain valves (1 and 4-
Fig. 1.5) and wait for at least 30 seconds (time needed for
the compressor to depressurize).
Electrical maintenance
Wait for at least 6 minutes before starting maintenance as
hazardous high voltage remains on the condensers of the
start and speed regulation unit for 6 minutes after
switching off the voltage.
Apply all relevant safety precautions, including those
mentioned in this book.
4.1 Preventive maintenance schedule for
the compressor 1)
Service plans
A number of service operations are grouped in plans, called
Service plans A, B or C. Each plan has a programmed time
interval at which all service actions belonging to that plan are
to be carried out.
When reaching the interval, a message will appear on the
screen indicating which Service plans are to be carried out.
See "User manual for Elektronikon regulator", section "Status
data menu".
After servicing, the intervals are to be reset. See "User manual
for Elektronikon regulator".
Important
Always consult Atlas Copco in case any timer setting should
be changed.
Service kits
For overhauling or carrying out preventive maintenance,
service kits are available. See section 4.8. Atlas Copco offers
several types of Service contracts, relieving you of all
preventive maintenance work. For more details, consult your
nearest Atlas Copco customers centre.
General
The schedule comprises a summary of the maintenance
instructions. Read the respective section before taking
maintenance measures. When servicing, replace all disengaged
packings, e.g. gaskets, O-rings, washers.
Preventive maintenance schedule
Period See See notes Operation
section below
table
Daily 3 - Check oil level
" 3 and 7 - Check readings on display
" -- - Check that condensate is discharged during operation
" 3 - Check air filter service indicator
" 3 - Drain condensate
3-monthly 5 - Check coolers and condenser of dryer; clean if necessary
" 5 1 Remove and inspect air filter element (AF)
