Atlas Copco LPD Series Operator Instructions

T he LPD requi res an oil flow of 20-30 l.p.m. and then
works at a pressure of 105-125 bar. For connection see
the secti on Connection to hydraul i c power source!
T -Connection
OilFlow Orifice ½“BSP ¾“JIC
18-22 l.p.m . 4.2 mm 1818013 1818012
23-26 l.p.m . 5.2 mm 1818120 1818122
27-30 l.p.m . None 1805711 1815135
P-Connecti on
½” BSP ¾ “JIC
1805711 1815135
Disconnecting the post driver
1 I so la te t he h yd rau li c su pp l y.
2 Di sconnect the hoses by pulli ng up the knurl ed
l ocki ng ri ngs and pull ing up the coupli ngs. Fi t blanki ng
caps to the hoses.
Hydraulic hoses
For connecti ng the post dri ver the hydrauli c hose shall
be approved for a worki ng pressure of at l east 140 bar
and have a ½” i nner di ameter. T o resi st exterior wear
and tear we recommend usi ng a 2-layer hydrauli c hose.
TheconnectiononthepostdrivermarkedwithaP
(pump) i s the entry poi nt for oil , and that m arked wi th a
T (tank) i s the exit point.
Quick release couplings
In the original , hydraul ic hoses are fi tted wi th
Fl at-Face qui ck rel ease couplings.
T hi s ki nd of qui ck release coupl ing i s stronger and
easi er to cl ean. The qui ck release coupli ngs are
fitted so that the mal e connecti on suppl ies the oil and
the femal e connection recei ves the oil .
Quick release coupli ngs shall be approved for a
minimum 140 bar work in g pressure.
Chan ging accessor ies
• Assembling the post driver with
adaptors.
1. Chose a sui table adaptor (see the accessori es)
for the pos t.
2. Rem ove the nuts from the bottom pl ate.
3. Fi x the adaptor to the dri ver by the fasteners.
Adap tors
3371806032 Square adaptor 54 mm
3371806033 Uni versal adaptor
3371806034 Round adaptor Ø96 m m
Uni versal adaptor:
Square post: M ax. 62x62 mm Rectangular post:
Max. 90x35 mm Round post: M ax. Ø62 mm
This section is intended as a guide to using the
post driv er.
5
WARNING
Hydraulic oil at pressure c an inj ure y ou. Follow
the instructions below f or connecting the hos es.
CAUTION
Do not operate t he LPD w ithout pressure
being applied e.g. Do not press the remot e
control (RC) or trigger on the LPD in the air.
Such repeated action may result in damage
to the LPD. If the energy supply to the LPD is
interrupted, releas e t he trigger (RC)
immediately to prevent damage.
WARNING
Alway s isolate t he post driver from the pow er
source when changing acc essories.
WARNING
Nev er re st the post or the adaptor in a driver on
your foot or against your body.
WARNING
N ever l ean a
g
ains t the
p
ost driver in order not to
lo o se fo ot ho ld, if t h e rod sh ou ld break by accid ent, or
if t h e p il e su dd enlysin ks.
3371806032 3371806033 3371806034
WARNING
Please read the maintenance instructions
carefully before using the hydraulic post
driv er for the first time .
When working in some materials
particles can fly. M ake sure no one else is
w ithin the w ork area.
Use recommended protective clothing
and equipment to protect yourself from
flying particles.
Disconnect the hy draulic power
source before the post is replaced or
before the post driver is serviced.
Alway s use posts with suitable
adaptor for the post driver.
Posts that not fit w ell in adaptors during
driv ing can caus e inj ury. Never use posts
tha t a r e m uc h w o r n or a r e da m a ge d on
shafts.
Alway s w ear protectiv e goggles,
protectiv e footwear and ear prot ectors
w hen using the post driver.
