Instruction book
2.4 Settings of overload relay - fuses - cable size
2.4.1 Settings of overload relay - fuses of compressors with DOL starter
50 Hz
Type Voltage Overload relay Fuses
(V) (A) (A)
LE/LF/LT2 230 (1-phase) 9.3 16
LE/LF/LT2 230 6.7 10
LE/LF/LT2 400 4.1 10
LE/LF2 500 3.5 10
LE/LF/LT3 230 (1-phase) 13.7 25
LE/LF/LT3 230 9.3 16
LE/LF/LT3 400 5.6 10
LF/LT5 230 15.7 25
LE/LF/LT5 400 9.3 16
LE/LF/LT7 230 20.3 25
LE/LT7 400 12.4 25
LT10 400 14.7 25
60 Hz
Type Voltage Overload relay Fuses
(V) (A) (A)
LE/LF/LT2 230 8.1 10
LE/LF/LT2 440 4.1 10
LE/LF/LT3 440 5.7 10
LE/LT5 380 11.1 25
LE/LT5 440 9.8 16
LE/LT5 460 9.4 16
LE/LT7 230 25.1 40
LE/LF7 440 12.8 25
LE/LT7 575 8.3 10
LE/LT10 230 28.5 40
LE/LT10 460 14.5 25
LE/LT10 575 11.7 25
LE15
230
39.9 63
LE15
460
20.2 40
LE20 575 19.9 40
2920 1585 00 - 43 -
