Instruction book
Torque value Torque value Torque value
M6: 10 Nm +/- 2 M8: 23 Nm +/- 2 M10: 46 Nm +/- 5
5.3 Air filter
1. Stop the compressor.
2. On LE/LF/LT2 up to -7, LE/LT10 50 Hz, LT15, -20 and LT15-30, LT20-30: unscrew the cap on top of
cover (1-Fig. 1.1). Lift off the cover and filter element. Take care that no dirt drops inside the suction
silencer.
On LE10 60 Hz, LF10 and LE15, -20: unscrew cap (1-Fig. 1.7) and take out the air filter. Take care
that no dirt drops inside the suction silencer.
3. Using a damp cloth, clean the filter chamber and cover. Discard damaged elements.
4. Install the new element, cover and cap.
2920 1585 00 - 56 -
