SmartROC T45/C50 5 Safety Functions
22
5.1.2ResettingtheEmergencyStop
!
NOTE:Resettheemergencystoponlyifitissafetostartthemachineorresumework.
1.
Iftheemergencystopisaknob,turnthedepressedemergencystopinthedirection
ofthearrows.Thisactionwillcausethebuttontorelease.Foranonrotationalbutton
withoutdirectionalarrows,pulltheemergencybuttonthathasbeenactivated.
2.
Pressthe'RESET'buttoninthecabin.
3.
Restartthemachineasperstartupinstructions.
5.2 ProtectiveGuard
Theprotectiveguardisasteelstructurefittedonthefeeder.Theprotectiveguardprovides
increasedsafetywhenthemachineisinoperation.
Thefollowingappliesforrigsequippedwithaprotectiveguard:
n Theprotectiveguardmustbeclosedduringdrilling.
