Atlas Copco XATS 250 PE Stage V APP User Manual

- 42 -
During loading the following display is shown
(default display)
The controller controls the speed of the engine in
order to meet the requested working pressure, at the
most economical fuel usage.
PRESSURE SETTING
To change the pressure setting there are two
possibilities.
1. Choosing between presets
The operator can choose between two preset
pressures.
The current active preset is indicated in the top
right corner of the display: 1 or 2. To switch to the
other preset, go to the Main view and press the
enter button for 2 seconds (the pressure set point
will light up in green).
By pressing the left or the right arrow button the
operator will be notified to:
“Press enter to go to other pressure setting X Y”
When enter is pressed the setting will become
active.
By pressing enter again the controller will go out
of edit mode.
The active preset presure (1 or 2) will be visible in
the top right corner of the display.
Active Buttons
MAIN VIEW
LOADED
7.2
1424RPM 7.2bar1286h
40%
MAIN VIEW
LOADED
7.2
1424RPM 7.2bar1286h
40%
MAIN VIEW
LOADED
1424RPM 7.2bar1286h
40%
7.2
