AudioEngine A5+ Setup Guide

audioengine A5+ setup guide
13
Audioengine 5+ Premium Powered Speakers
General Specications
Power Consumption
Idle, Mute, Sleep:
8t8t4W
10.75” (27 cm) x 7” (18 cm) x 7.75” (20 cm) each
15.4 lbs (7 kg)
MCTLH
31 lbs (14 kg)
11.5” (W) x 14.5” (H) x 21.75” (L)
Dimensions (HWD):
Weight (Left):
Weight (Right):
Shipping weight:
Shipping box dims:
Environmental
Requirements:
tOperating temperature: 32° to 88°F (0° to 31°C)
t
Non-operating temperature: -4° to 113°F (-20° to 45°C)
tRelative humidity: 5% to 95% non-condensing
2.0 powered (active) speaker system
150W peak power total
(50W RMS, 75W peak per channel), AES
Dual Class AB monolithic
5" Kevlar woofers, 20mm silk dome tweeters
3.5mm stereo mini-jack, RCA L/R
RCA L/R audio (full-range, adjustable)
USB Type A (power/charge)
7)[NBOVBMMZTXJUDIBCMF
>95dB (typical A-weighted)
<0.05% at all power settings
<50db
50Hz-22kHz ±1.5dB
10K ohms unbalanced
Output current limiting, thermal over-temperature,
power on/o transient protection, replaceable
external main fuse
Power output:
Amplier type:
Drivers:
Type:
Inputs:
Outputs:
Voltages:
Signal-to-noise:
THD:
Crosstalk:
Frequency response:
Input impedance:
Protection:

AudioEngine A5+ Specifications

General

Product color	White
Housing material	-
Recommended usage	Universal
Remotely operated	Yes
Suitable for outdoor use	No
Magnet type	Neodymium
Tweeter diameter	20 mm
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Woofer diameter (imperial)	5 \
Amplifier class	A/B
Impedance	- Ω
Frequency range	50 - 22000 Hz
RMS rated power	50 W
Signal-to-Noise Ratio (SNR)	95 dB
Peak Music Power Output (PMPO)	150 W
Total Harmonic Distortion (THD)	0.05 %
Cables included	AC, Audio (3.5mm)
Connectivity technology	Wired
AC input voltage	115 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	4 W

Weight and Dimensions

Depth	200 mm
Width	180 mm
Height	270 mm
Weight	11400 g
