audioengine A5+ setup guide
Setup and Operation
6
Step 1 - Speaker Placement
Although your Audioengine 5+ speakers are very forgiving with
regards to placement, it’s true that proper speaker placement can
have an impact on sound quality. There seem to be dierent theories
on correct speaker placement but rooms and tastes are dierent so it’s
dicult to recommend a perfect setup. We do suggest you feel free to
experiment to see what works for you.
As a general rule of thumb for the best soundstage and imaging, the
speakers should be equidistant from side walls and a dierent distance
from rear walls. Tweeters should be at about eye-level in your most
frequent listening location and for the best bass response we recom-
mend at least 6 inches of clearance between the rear of the speakers
and the wall behind them.
Here are a few more suggestions, assuming you have some exibility
regarding where you place your speakers. No need for concern if your
situation and listening environment dictate the speakers’ position.
t Both speakers should be equidistant from your primary listening
position.
t Placing the speakers at least 6 feet (1.8m) apart usually provides the
best imaging.
t Try to keep the speakers near the front edge of shelves or cabinets.
t Allow at least 6 inches of clearance between the rear of the speakers
and the wall or surface behind them.
t If you need to turn the speakers on their sides, position the tweeters
toward the outside.
t If used on a desktop for computer speakers, it’s best if they are
placed on a solid surface

Other manuals for AudioEngine A5+

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AudioEngine A5+ and is the answer not in the manual?

AudioEngine A5+ Specifications

General IconGeneral
Product colorWhite
Housing material-
Recommended usageUniversal
Remotely operatedYes
Suitable for outdoor useNo
Magnet typeNeodymium
Tweeter diameter20 mm
Speaker placementTabletop/bookshelf
Audio output channels2.0 channels
Woofer diameter (imperial)5 \
Amplifier classA/B
Impedance- Ω
Frequency range50 - 22000 Hz
RMS rated power50 W
Signal-to-Noise Ratio (SNR)95 dB
Peak Music Power Output (PMPO)150 W
Total Harmonic Distortion (THD)0.05 %
Cables includedAC, Audio (3.5mm)
Connectivity technologyWired
AC input voltage115 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)4 W
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width180 mm
Height270 mm
Weight11400 g
