AudioEngine A5+ Setup Guide

audioengine A5+ setup guide
5
A5+ Back Left A5+ Back Right
115
Output to
Passive Speaker
Variable Output
Audio Input 2
Power On/O
Voltage Select
AC Power Inlet
Audio Input 1
USB Power
Remote Control
Mute
Press the Mute button to silence the A5+. The front panel
indicator will blink showing that the speaker is muted. Press
Mute again to unmute the volume.
Note that you can also bring the A5+ out of mute by pressing
Volume (+) or (-) or turn the front panel volume knob.
Volume
Press Volume (+) or (-) to adjust the A5+ volume level.
Sleep
This button puts A5+ into a power-saving Sleep Mode, shown
by the front panel power indicator as a slow pulse. To exit
Sleep press the Sleep button again.
Note that you can also put the A5+ into and out of Sleep
Mode by pressing the front panel volume knob.

AudioEngine A5+ Specifications

General

Product color	White
Housing material	-
Recommended usage	Universal
Remotely operated	Yes
Suitable for outdoor use	No
Magnet type	Neodymium
Tweeter diameter	20 mm
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Woofer diameter (imperial)	5 \
Amplifier class	A/B
Impedance	- Ω
Frequency range	50 - 22000 Hz
RMS rated power	50 W
Signal-to-Noise Ratio (SNR)	95 dB
Peak Music Power Output (PMPO)	150 W
Total Harmonic Distortion (THD)	0.05 %
Cables included	AC, Audio (3.5mm)
Connectivity technology	Wired
AC input voltage	115 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	4 W

Weight and Dimensions

Depth	200 mm
Width	180 mm
Height	270 mm
Weight	11400 g
