11
4. Refrigerant System Diagram
4-1 Cooling Only
3 Cooling Mode
4 Cooling Cycle
Compressor
(Compression)
Outdoor heat exchanger
(Condensation)
Steam-gas of low pressure
Super cooled liquid of high
pressure
Liquid of low
pressure
(also a little gas)
Gas of high pressure &
temperature
Indoor Unit
Outdoor Unit
