73
10. Removal Procedure
Stop operation of the air conditioner and remove the power cord before repairing the
unit.
10-1 Indoor Unit
Part
Procedure
Diagram
1
1) Turn off the power,
hold the middle panel
with the middle finger,
2) open the panel
upwards, remove the
panel fixing shaft, and
remove the panel.
2
Remove front Panel
