6
Assembly Instrucons
Step 1
Assemble the boom shelf (23) to
the legs (20) using BOLT M6*50 (AA)
- 4 PCS and NUT M6 FLANGE LOCK
(EE) - 4 PCS.
Step 2
Assemble the long fence rails (21) to
both legs using BOLT M6*12 (BB) - 8
PCS.
