16
Service Support - M/C
Service Station Manual
Parameter
Specification Pulsar F250 / N250
Type
2 Valve, Single cylinder, oil cooled
Bore 72 mm
Stroke 61.17 mm
Displacement 249.07 cc
Idling speed 1500 ± 100 rpm
Max.Net Power 24.5 PS @ 8750 rpm
Max. Net Torque 21.5 N.m @ 6500 rpm
Ignition system DC, Fuel Injection
Spark plugs Qty 2 Nos
Spark plug gap 0.8 - 0.9 mm
Lubrication Wet Sump Forced Lubrication
Transmission
5 Speed, Constant mesh
Gear shifting pattern
1 Down, 4 Up
Engine oil Grade
-
SAE 20W50 JASO MA2 API SN
Engine oil Drain & Refill quantity
1300 ml
Overhaul quantity 1700 ml
Frame
Tubular frame
Suspension
Front
Front : Telescopic suspension
Rear
Rear : Mono suspension, without canister
Brakes
Front
Single channel ABS,
Disc Ø 300 mm
Rear Disc Ø 230 mm
Tyres
Front 100/80-17, 52P, Tubeless
Rear 130/70-17, 62P, Tubeless
Tyre Pressure
Front 1.75 Kgf/cm² (25 PSI)
Rear (Solo) 2 Kgf/cm² (28 PSI)
Rear (Pillion) 2.25 Kgf/cm² (32 PSI)
Fuel Tank Capacity Full 14 Litres
Fork oil Grade
Bajaj Genuine, SAE 10W20
Fork oil Quantity / leg
342 ml
Frame
Engine
TECHNICAL SPECIFICATIONS
