A. Electric Scooter Assembly
20. Slide rear wheel away from frame
mounting slots.
21. Slowly remove rear wheel from
cam.
Attention:
Give particular attention to the power
cable, when removing rear wheel.
22.Carefully loosen all four mounting bolts
securing electric motor to rear wheel.
Attention:
The 750 watt electric motor is very
heavy. Exercise caution while
removing motor mounting bolts.
1. Loosen and remove four mounting
bolts securing 750 watt motor to rear
wheel.
Electric Motor Removal
