Baur PGK 50 User Manual

4-4
4. Performing High Voltage Test
Determine resistance value
By means of a diagram and with the measured current and voltage
values:
- determine the appropriate resistance value.
0
2
0
4
0
6
0
8
0
1
0
0
U [kV]
I
10n
25n
50n
100n
250n
500n
1µ
2,5µ
5µ
10µ
25µ
50µ
100µ
250µ
500µ
1m
2,5m
5m
10m
25m
50m
5710 20
30
40 50 70
1M
2,5M
5M
10M
25M
50M
100M
250M
500M
1G
2,5G
5G
1T
500G
250G
100G
50G
25G
10G
I / A
U / kV
R / Ω
Diagram
Voltage U, Current I
® Resistance R
Example
I = 10 µA, U = 10 kV
® R = 1 GW
Observe selected measuring ranges
U
I
R
