Baxi Duo-tec Combi GA User Manual

14
Technical Helpline: 0844 871 1525
5mm Min
450mm Min
For servicing
purposes
In operation
At least 1.5°
345mm*
150mm Min
763mm
450mm
5mm Min
170mm
106mm
5
mm
M
i
n
17
0
0m
m
m
m Min
(
30
2
5m
m
M
in if usin
g
80
/
1
2
m)
fluein
g
syste
m
Duo-tec Combi GA
Clearances
Baxi Duo-tec Combi GA pipe connection
Above: 175mm
Left: 5mm
Right: 5mm
**This is MINIMUM recommended dimension. Greater clearance will aid installation and maintenance.
Baxi Duo-tec Combi GA
Max DHW
Output
(KW)
Flow Rate
(l/m) @
35° Max)
CH Output
(kW)
Sales Code
Duo-tec Combi 24 GA 24 9.8 3.4 to 20 720117801
Duo-tec Combi 28 GA 28 11.5 3.8 to 24 720118001
Duo-tec Combi 33 GA 33 13.5 4.7 to 28 720118201
Duo-tec Combi 40 GA 40 16.4 5.7 to 33 720118401
Below: 150mm**
Front 5mm (in operation)
450mm (for servicing)
*355mm with control panel ap
345mm*5mm Min
In operation
450mm Min
For servicing
purposes
Boiler
Side
Boile
r
Side
Heating
Flow
(22mm)
Hot Water
Outlet
(15mm)
Gas
Inlet
(22mm)
Cold Water
Inlet
(15mm)
Heating
Return
(22mm)
Pressure
Relief
Valve
(15mm)
Condensate
Drain
65 mm 65 mm 65 mm 65 mm 95 mm45 mm
192 mm
50 mm
At least
1.5°
MX8013 - Technical pocket guide DL v14_post proof.indd 14 30/08/2012 14:29
