30
Technical Helpline: 0844 871 1525
150mm Min
700mm
390mm
175mm Min
(300mm Min if
using 80/125mm
flueing system)
5mm Min
5mm Min
162mm
106mm
(450mm - 32kW model)
(763mm -
32kW model)
Megao System Compact GA
Clearances
Above Flue: 175mm
Left: 5mm
Right: 5mm
Below: 150mm**
Front 5mm (in operation)
450mm (for servicing)
**This is MINIMUM recommended dimension. Greater clearance will aid installation and maintenance.
*300mm with control panel ap
5mm
Min
5mmMi
n
450
mm Mi
n
F
or servicing
purpose
s
I
n operation
At
least
1.5°
290mm
290m
m*
150mm Min
390mm
175mm Min
(300mm Min if
using 80/125mm
flueing system)
5mm Min
5mm Min
700mm
Heat Output
(kW)
Sales Code
Megao System Compact 12 GA 2 to 12 720118501
Megao System Compact 15 GA 2.1 to 15 720118601
Megao System Compact 18 GA 2.5 to 18 720118701
Megao System Compact 24 GA 3.4 to 24 720118901
Megao System Compact 28 GA 4 to 28 720119101
Baxi Megao System Compact GA pipe connection
Heating
Flow
(22mm)
Gas
Inlet
(22mm)
Heating
Return
(22mm)
Pressure
Relief
Valve
(15mm)
Condensate
Drain
130 mm
25
mm
130 mm 65 mm40 mm
162.5 mm
Boile
r
Side
Boiler
Side
Baxi Megao System Compact GA
Output: 12,15,18, 24 and 28kW
MX8013 - Technical pocket guide DL v14_post proof.indd 30 30/08/2012 14:29
