Neta-tec Combi GA
Clearances
Above: 175mm
Left: 5mm
Right: 5mm
**This is MINIMUM recommended dimension. Greater clearance will aid installation and maintenance.
For sales codes that include standard ue see page 10.
Baxi Neta-tec Combi GA
Below: 150mm**
Front 5mm (in operation)
450mm (for servicing)
150mm Min
700mm
390mm
162mm
106mm
5mm Min 5mm Min
175mm Min
(300mm Min if
using 80/125mm
flueing system)
5mm Min
450mm Min
For servicing
purposes
In operation
At least 1.5°
290mm
*
5mm Min
In operation
290mm*
*300mm with control panel ap
Max DHW
Output
(KW)
Flow Rate
(l/m) @
35° Max)
CH Output
(kW)
Sales Code
Neta-tec Combi 24 GA 24 9.8 3.4 to 20 720023001
Neta-tec Combi 28 GA 28 11.5 3.8 to 24 720023101
Neta-tec Combi 33 GA 33 13.5 4.7 to 28 720023201
Baxi Neta-tec Combi GA pipe connection
Heating
Flow
(22mm)
Hot Water
Outlet
(15mm)
Gas
Inlet
(22mm)
Cold Water
Inlet
(15mm)
Heating
Return
(22mm)
Pressure
Relief
Valve
(15mm)
Condensate
Drain
40 mm
25
mm
65 mm 65 mm 65 mm 65 mm 65 mm
162,5mm
Boiler
Side
Boiler
Side
At
least
1.5°
450mm Min
For servicing
purposes
