Baxi EcoBlue System 12 User Manual

60 EcoBlue System 7219708 - 01 (04/15)
10 Maintenance
10.3.15 Hydraulic Pressure Sensor (Fig. 63)
1. Close the flow and return isolation taps and drain the primary
circuit. For ease of access remove the fan and collector
assembly.
2. Remove the plug from the sensor and pull the retaining clip
forwards. The clip is captive and does not need to be fully
removed.
3. Reassemble in reverse order.
Hydraulic
Pressure Sensor
Securing Clip
(captive)
Plug
Fig. 63
