Bay-Tek Spin-N-Win! User Manual

46
PARTS LIST
17
PART # DESCRIPTION
PART # DESCRIPTION
A5CB8020 COIN BOX
A5HA8500 HANDLE MECH ASSY
A5RO8700 PULL HANDLE ROD
A5CA8704 CAM, STANDARD
A5HU8500 HUB, SMOOTH, CHROME
A5PL8708 CHROME PLATE FOR HANDLE
A5CORD5 CORD,AC COMPUTER CORD
A5LD6900 LED BULB (128 PER GAME)
AACE6946 SECIAL LED BULB (4 PER GAME)
AACBL4A-DOOR
CABLE, DOUBLE COIN DOOR
A5FI9010 FILTER,INLINE,TO PASS FCC
A5LK2001 LOCK, CASH BOX, A05/E00 KEY
A5LK5002 LOCK, 7/8", H95 KEY CODE
AAPB5900 PUSH BUTTON,RED,W/LEDS
AASW200 LOW TICKET SWITCH
A5TD1 TICKET DISPENSER,ENTROPY
A5TT4100 LEFT TICKET TRAY
A5TT4101 RIGHT TICKET TRAY
A5ME4182 METAL COIN BOX GUIDE
A5ME4179 LEFT TICKET DISP BRACKET
A5ME4180 RIGHT TICKET DISP BRACKET
A5PL4200 PLATE, MOUNT BILL VALIDATOR
A5TB6900 TERMINAL BLOCK
A5HO1003 HOLDER FOR LIGHT BARS
A5PL8900 BLANKING PLATE FOR DBA
W5HG1025 16" Double Bend Hinge
W5HG1050 8" Double Bend Hinge
W5HG1065 5-75 Single Bend Hinge
A5ME6900 METAL, FRONT KICK PLATE
A5ME6901 METAL, FRONT CAB BRACKET
A5ME6902 METAL, TOP CABINET BRACKET
A5ME6903 METAL, LEFT LEG ASSEMBLY
A5ME6904 METAL, RIGHT LEG ASSEMBLY
A5RI6900 RIVOT, NYLON PUSH RIVOT
W5TM4000 T-MOLD,7/8""BLACK
A5LD1052 LED DISPLAY MODULE
AACB3904 CIRCUIT BD, RIBBON SPLITTER BD
AACB6921
LIGHT CONTROL BOARD
AANEWGEN1-RBN
BD ASSY,NEWGEN,W/RIBBON
AAPB2700 PUSHBUTTON, MENU, ASSY
AACO3325 COUNTER,ASSY
A5PS6900 24 V DC POWER SUPPLY
AAPS1013-SNW POWER SUPPLY ASSEMBLY
AACE3219 CABLE,TKT DISP/LOW TKT
AACE6900 CABLE ASSY, LOWER HANDLE, TICKET
AACE6901 CABLE ASSY, SPEAKERS
AACE6902 CABLE ASSY, NEW GEN POWER
AACE6904 CABLE ASSY, POWER TO CONTROL BD
AACE6905 CABLE ASSY, BUTTON/LIGHT SWITCH
AACE6908 CABLE ASSY, SPEAKER WIRE
AACE6909 CABLE ASSY, PLAY BUTTON
AACE6910 CABLE ASSY, 12 VOLT TO LED LIGHTS
AACE6913 CABLE ASSY, METERS/MENU BUTTONS
AACE6914 CABLE ASSY,DATA AND PLAYFIELD LIGHTS
AACE6918 CABLE ASSY, DBA
AACE6919 CABLE ASSY, OUTLET STRIP
AACE6921 CABLE ASSY, 12 V TO MARQUEE LIGHTS
AACE6922 CABLE ASSY, 12 VOLT TO LED LIGHTS
AACE6923 CABLE ASSY, RIBBON CABLE
AACE6924 CABLE ASSY, RIBBON CABLE
AACE6925 CABLE ASSY, RIBBON CABLE JUMPER
AACE6926 CABLE ASSY, 12V POWER SUPPLY
AACE6927 CABLE ASSY, GROUND JUMPER
AACE6928 CABLE ASSY, COIN UP FROM NEW GEN
AACE6929 CABLE ASSY, POWER CORD JUMPER
AACE6930 CABLE ASSY, MARQUEE STICK LIGHTS, 8 IN
AACE6931 CABLE ASSY, MARQUEE STICK LIGHT, 8 IN
AACE6933 CABLE ASSY, TOP PLAYFIELD LIGHT, 40 IN
AACE6934 CABLE,OUTSIDE LIGHTS IN UPPER PLAYF
AACE6936 CABLE ASSY, STICK LIGHTS, 45 IN
AACE6938 CABLE ASSY, BULB JUMPER
AACE6939 CABLE ASSY, PLAYFIELD BULB POWER
AACE6940 CABLE ASSY, LIGHT BULB POWER
AACE6941 CABLE ASSY, MARQUEE POWER JUMPER
AACE6942 CABLE ASSY, MARQUEE POWER
AACE6943 CABLE ASSY, PLAYFIELD DISTR. BOARD
AACE6944 CABLE ASSY, COM TO CONTROL BD,
AACE6945 CABLE ASSY, PLAYFIELD LIGHT, 12 IN
AACE6946 SECIAL LED BULB (4 PER GAME)
AACE6947 CABLE,MALE ADDRESSABLE LIGHT JUMPER
AACE6948 CABLE,FEMALE ADDRESSABLE LIGHT JUMP
AACE6950 CABLE ASSY, DISPLAY JUMPER RIBBON
AACE8811 SPEAKERS
AACE6937 CABLE ASSY, TOP JUMPER POWER SUPPLY
AACE6932 CABLE ASSY, MARQUEE STICK LIGHT, 40 IN
AACE6906 CABLE, 12 V JUMPER TO MARQUEE LIGHTS
