Commissioning/Configuration
5. Select the option PCI/PCIe device.
If the option Onboard/ISA device is already selected, the option PCI/PCIe device is greyed out and
cannot be selected.
The option PCI/PCIe device can be re-enabled as follows:
6. Click on Search.
The window Device Found At appears.
7. Click on the COM port, then on OK.
The option PCI/PCIe device is enabled again.
ð You have successfully added and configured the CX51x0 with serial interface (N031x) in TwinCAT. You
can now add further devices to the device and continue with the configuration.
CX51x0 81Version: 1.6
