Commissioning/Configuration
5.3.2 Operation with TwinCAT3
Once the CX was selected as target system, the CX with serial interface can be added to the tree view under
TwinCAT.
Prerequisites for this step:
• A scanned and selected target system.
Add the CX51x0-N03x as follows:
1. In the tree view on the left, right-click on Devices.
2. In the context menu click on Scan.
The window new I/O devices found appears.
3. Select the device with a COM port and confirm the selection with OK.
The CX51x0-N03x is added in TwinCAT as Device (COM Port) in the tree view on the left.
4. Click on Device (COM Port) and then on the Serial Port tab.
CX51x082 Version: 1.6
