EXPLODED VIEW
Before using your EDP, see it inside out.
For this, please refer to the exploded view on p4
To assemble your product, please refer to the assembly diagram on p9.
24
N°
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Designation
Right brake
Left brake
Acceleration trigger
Ignition key
Folding handle
Charging connector
Speed calculator
Battery (depending on version)
Footrest platform
Saddle pin
Engine
Pinion driving the chain
Mud guard
Front and rear brake caliper
Front and rear brake pads
Chain
N°
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Designation
Rear transmission crown
Rear rim
Rear tire
Front & rear air chamber
Rear fork
Rear shock absorbers
Crutch
Front rim
Front brake disc
Front tire
Front shock absorber
Front fork
Tool kit
Charger
Saddle
Saddle mast
ASSEMBLY
• Please follow the assembly instructions carefully.
• Without the fuse, the scooter cannot start
• Tightening torque: tighten up to the stop and then an additional 1/4 turn
a. Safety pin for folding
b. Safety pin for the saddle
vs. Fuse
d. Allen key n ° 4
e. Allen key n ° 5
f. Allen key n ° 6
g. Allen key n ° 10
h. English key n ° 8 & n ° 10
i. English key n ° 15 & n ° 18
j. English key n ° 19 & n ° 17
k. Double ambout cruciform & flat screwdriver
l. Double ambout screwdriver handle
mr. Tire inflation valve adapter
Only valid for models FX1600-S and FX1600
Your scooter is delivered to you with the deflated rear tire.
Please inflate your tire to 2.5 to 3 bar before continuing to assemble the scooter.
