Behringer ABACUS User Manual

66 67Quick Start Guide
ABACUS
Specications
Inputs CV 1-4, Trig 1-4, Rise 1 & 4, Fall 1 & 4
Both 1 & 4, Cycle 1 & 4: 3.5 mm jack
Outputs CV 1-4, OR, SUM, INV, ƒ1 & 4, 1 EOR, 4 EOC
3.5 mm jack
Controls 1 & 4 Rise, 1 & 4 Fall, 1 & 4 Response knobs
1 - 4 attenuverter knobs
1 & 4 Cycle buttons
Impendances Rise & Both CVs: 100 kΩ
Fall CVs: 33 kΩ
CV Inputs 1 & 4: 33 kΩ
CV Inputs 2 & 3: 75 kΩ
Trigger Inputs: 100 kΩ
Cycle Trigger Inputs: 50 kΩ
Outputs 1-4, INV, SUM, OR: 680 Ω
EOR/EOC: 2.2 kΩ
ƒ 1 & 4: 100 Ω
Sensitivities Trigger 1 & 4: 4 V minimum
Cycle 1 & 4: 1.8 V minimum
Power Consumption 60 mA +12 V / 50 mA -12 V
Dimensions 20 hp
10 cm x 12.8 cm x 2.4 cm
(3.94 " x 5.04 " x 0.94 ")
Weight 191 g (6.74 oz)
Packaged Weight 284 g (10.02 oz)
