Behringer T-1 User Manual

5 TUBE CONDENSER MICROPHONE T-1 User Manual
Set-up3.
Mounting the microphone
The microphone comes with an elastic shockmount. The advantage to a
conventional microphone stand mount is that mechanically induced noise
is virtually absorbed.
To mount the microphone, attach the shockmount to the microphone stand
and, from above, slide the T-1 into the shockmount.
Caution !
The provided shockmount is not intended to be used for ◊
suspending the T‑1!
Alternatively, you can also mount the T-1 on a microphone stand mount.
There is a screw adapter on the bottom side of the microphone.
Warming up
The T-1 can basically be used a couple of seconds after the PSU-T has been
switched on. However, the typical sound of the the T-1 only unfolds a while
after activating the power supply. We recommend allowing the microphone
to “warm up” 30 minutes before use.

Behringer T-1 Specifications

Physical Dimensions

transducer type	16 mm (0.63")
dimensions	shaft: 68 mm, length: 211 mm
weight	0.77 kg

Audio Specifications

frequency response	20 Hz to 20 kHz
open circuit sensitivity	-40 dBV (0 dBV = 1 V/Pa)
max SPL	130 dB

Electrical Specifications

nominal impedance	approx. 200 Ω
supply voltage adapter	BEHRINGER PSU-T
mains voltage	100-120 V~, 50/60 Hz T 250 mA H 250 V / 220-230 V~, 50/60 Hz T 125 mA H 250 V
