TRK 502/ 502X
24
Fog Lamp Connector
1. HORN BUTTON
Press down on the button, to activate the horn.
2. HIGH & LOW BEAM SWITCH
Turn the switch to " " position, the high beam of headlamp turn
on and the indicator lamp on the meter would also turn on; turn
the switch to " " position, the low beam of headlamp turn on.
3. DIRECTION INDICATOR LAMP SWITCH
Turn the switch to " " position, the left direction signal lamp ashes; turn the switch to " " position, the
right direction signal lamp ashes. And the indicator lamps would turn on accordingly.
4. PASSING SWITCH
When passing other vehicles, press this button so the high beams of the headlamp would ash to alarm the
vehicles in front of you.
5. FOG LAMP SWITCH (IF EQUIPPED)(THE MAXIMUM CURRENT IS 2A)
Press the button to turn on the fog lamp, press again to turn o.
PRIMARY PARTS
1
3
5
2
4
LEFT HANDLE (B)
