SIENA AirJet (#54156)
S-S-004675/21x28.5cm/54112AU 54123AU 54129AU 54148AU 54154AU 54156AU 澳规SPA说明书/JS-YF-2016-B-05546/英
S-S-004675
11
3.2.
1.
4.
5. 6.
To stop inflation.
3 seconds to unlock.
7.
1
0.08Bar(1.2PSI)
Inflate for 5 min.
C
o
n
t
r
1
2
Inflate for 2 min.
8. 9.
MAX.
MIN.
10.
11.
X
PUMP OPERATION
RESET
Heating Reset
When using the Lay-Z-Spa for first time, or after a long period of inactivity, be sure to press the reset button on
the pump using a small and thin object.
If the temperature on the control panel (or the water temperature) has not changed 4-5 hours after activation of the heating
system, use a thin object to press the RESET BUTTON, and restart the heating system.
IMPORTANT: The heating System will not operate if the outside temperature is above 40ºC (104 ºF) or if the Lay-Z-Spa is
under direct sunlight. Under these conditions, please wait until a cooler time of day before pressing the RESET BUTTON with
a thin object and restart the heating System.
Pressing the Temperature Increase or Decrease buttons will cause the LED to
flash. When it is flashing you can adjust to the desired temperature setting. If
you hold these buttons down the values will rapidly increase or decrease. The
new and desired temperature setting will remain on the LED display for 3
seconds to confirm the new value.
Once powered-up the LED displays the current water temperature automatically.
After 72 hours of filtration (without using the power saving timer function),
the pump will hibernate and flash “End” with the current water
temperature. When the pump is hibernating both the heating and water
filter functions are disabled. To re-activate the pump press lock/unlock
button for 3 seconds.
This button turns the filter pump on and off.
The light above the Water Filter Button displays red when activated.
Use this button to activate the heating system. When the light above the heat button
is red, the heating system is activated. When the light is green, the water is at the set
temperature and the heating system is at rest.
The temperature can be displayed in either Fahrenheit or Celsius.
NOTE: If the heating system is activated the filtration system will automatically start.
NOTE: After turning off the heating system the filtration system will continue to operate.
NOTE: The default temperature is 35°C (95°F).
NOTE: Temperature adjustment ranges from 20°C (68°F) to 40°C (104°F).
RESET BUTTON
IMPORTANT INSTRUCTIONS FOR USING
G
Temperature Adjustment Buttons
Lock/Unlock Button
A
C
Water Filter Button
Celsius/Fahrenheit Toggle
D
Heat Button
E
F
Use this button to activate the massage system, which has a 30-minute
auto-shutoff feature. The light above the Lay-Z-Massage System Button displays
red when activated.
IMPORTANT: Do not run the Lay-Z-Massage system when the cover is
attached. Air can accumulate inside the spa and cause irreparable damage
and bodily harm.
NOTE: Heat and massage system work together to create a warm
massage experience.
Lay-Z-Massage System Button
I
LED Display
J
NOTE: The water heat rate may change in the conditions below:
• When the outdoor temperature is below 15°C (59°F).
• If the cover is not in position when the heating function is activated.
NOTE: To display the current water temperature, run the filter system for at least a minute. The
water temperature as tested by an external thermometer may vary from the temperature as
displayed on the spa panel by as much as approximately 2°C.
B
J
H
G
F
E
D
A
C
I
H
Press this button for 2 seconds to active the control panel bottons and the light
turns to green. Press this button for 2 seconds to turn off all currently activated
functions.
On/Off Button
The pump has a 5-minute auto-lock. The LED light will dim out when the pump is
locked (no function is activated). To lock or unlock the pump, place a finger over the
lock/unlock button for 3 seconds.
Power-Saving Timer Button
B
This is a newly added function, designed to help avoid wasting power by setting
the time and duration of the heating cycle for the spa.
This way, you can enjoy your spa at the time you desire, without needing to leave
the heater on at all times.
STEP 1: Set the heating duration
1. Press the button unit the LED starts to flash.
2. Press the or button to adjust the heating duration (From 1-48 hours).
3. Press the button again to confirm the heating duration.
STEP 2: Set the number of hours FROM NOW when the heater will activate
1. After setting the heating duration, the LED starts to flash.
2. Press the or button to adjust the hours until time of activation (From0-99 hours).
3. Press button again or simply touch nothing for 10 seconds to confirm
the setting.The LED will light steadily, and the countdown to heater activation will begin.
To modify the timer settings: Press the button and use the or button to adjust.
Cancel the setting: Press the button for 2 seconds.
NOTE: After setting, the screen flashes the current temperature and time alternately.
NOTE: Timer adjustment (amount of time with the heater ON) may be set from 1 to 48 hours;
Reservation time adjustment (the number of hours FROM NOW when the
heater will begin to function) may be set from 0 to 99 hours. If the timer is set at 0 hour, the
heating system will activate immediately.
Note that the timer is one time per use - the user sets the duration of the heating cycle, and
how many hours from now the heating cycle begins. The timer does NOT repeat until reset.
Power-Saving Timer LED
.
This LED flashing means you are setting the heating duration. The light will be on
when the heating function starts to work.
This LED flashing means you are setting the number of hours FROM NOW when the
heater will activate. When the light is on, the Power-Saving Timer function is set.
