Bilt TEETER DEX II User Manual

USER SETTINGS
8
Figure 7a
Figure 7b
Figure 8
Figure 9
Adjust the Height of the Lap Pad
Figure 7a-7b: The Lap Pad needs to be adjusted so that
while standing on the Base Frame platform, your hips are
aligned with the top edge of the Lap Pad.
Figure 8: Loosen the Derattler Knob by rotating it several
turns counterclockwise.
Figure 9: While holding the Height Adjustment Handle
on the Lap Pad, pull the Height Adjustment Locking Pin
and lift or lower the Lap Pad to your ideal height. Release
the Locking Pin so that it engages fully into one of the
height settings. Tighten the Derattler Knob by rotating
clockwise.
ALWAYS ensure that all parts are assembled correctly
and read the User Settings/How to Invert thoroughly
before using your Teeter DEX II. Improper assembly or
settings could result in serious injury or death!
WARNING
!

Bilt TEETER DEX II Specifications

General

Brand	Bilt
Model	TEETER DEX II
Category	Fitness Equipment
Language	English
