Chapter 1 Motherboard Description
5%*
1.6.2 CPU Frequency Selection : JP1
JP1
FREQ.
123456
66MHz
OPEN OPEN CLOSE CLOSE CLOSE CLOSE
100MHz
OPEN OPEN OPEN CLOSE OPEN CLOSE
133MHz
OPEN OPEN OPEN OPEN CLOSE OPEN
NOTES: After version 1.0, the ATX POWER (POWER1) will be
removed just beside the KB/MS (CN1) & USB (USB1) port. ( in vertical
position)


