Troubleshooting
13
www.bissell.com
Reduced spray or no spray.
Possible Cause Remedies
1. Bladder may be empty. 1. Refill bladder with hand hot tap water.
2. The lint screen may be clogged 2. Clean out lint screen.
3. Tanks may not be seated properly. 3. Turn power OFF ( 0 ); remove &
reseat tanks.
4. Pump may have lost prime. 4. Turn power OFF ( 0 ); after 1
minute turn ON and press spray trigger.
5. The pump belt may be broken. 5. Turn power Switch OFF ( 0 ) and unplug
from the outlet. To check if a pump
belt has broken, you will need a flat
head screwdriver. Insert the blade end
into the lower slot of the belt access
door to release the lower snap. If
necessary, insert the balde end into the
upper slot to release the upper
snap. Examine the belt for breakage.
You should be able to see the pump
belt looped around the motor shaft. If it
is broken or missing, please refer to
Replacement Parts on page 15 before
calling BISSELL Consumer Services.
Complete installation instructions
will accompany the replacement belt.
Cleaner not picking up solution.
Possible Causes Remedies
1. ReadyTools dial may be on the 1. Set ReadyTools dial to either floor
wrong setting for the cleaning job. cleaning or tools.
2. Nozzle window may not be 2. Press down firmly on the black
properly attached. oval gasket at the top window to
make sure the two tabs on the
back of the nozzle window are
snapped into the mating slots in
the main housing.
3. Tank-in-tank lid is not properly installed. 3. Re-install lid; refer to page 8.
4. Tank-in-tank is not properly seated. 4. Tank-in-tank must be firmly
seated to function; remove and
reseat tank-in-tank.
5. Poor tool position. 5. Adjust angle; apply more
(Hand held attachments only). downward pressure.
6. Tank-in-tank has picked up 6. Empty tank-in-tank, refer to
maximum dirty water. page 9.
WARNING:
To reduce the risk of
fire, electric shock or
injury, unplug from the
outlet before servicing.
Insert
Screwdriver
Blade Here
Lift Here
To Next Page
