23
E88 Complete Vehicle
Layout of the Hydraulic Control Unit
The hydraulic pump is located in the right side section of the trunk.
The benefits of this location are:
• Maximum distance between the pump and the driver for noise suppression.
• Hydraulic lines are easily concealed by the luggage compartment trim.
• Ease of accessibility for service and repair.
Index Explanation Index Explanation
1
Hydraulic control unit
2
Trunk divider
Cut away view of luggage compartment from the rear
