Remove screw 1 at the front
right.
Remove screws 2.
Begin by pulling the side panel
out of holder 3, then pull it to
the rear to disengage it from
holder 4.
Remove the side panel.
Installing right side panel
Begin by seating the side pan-
el in holder 4, then seat it in
holder 3.
Install screws 2.
Install screw 1 at the front
right.
Install the seat ( 42)
8
99
z Maintenance

BMW G 650 Xchallenge Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Power	53 hp (39 kW) @ 7000 rpm
Torque	60 Nm (44 lb-ft) @ 5250 rpm
Transmission	5-speed
Seat Height	930 mm (36.6 inches)
Dry Weight	144 kg (317 lbs)
Fuel System	Electronic Fuel Injection
Fuel Capacity	9.5 liters
Front Brake	Single 300 mm disc, 2-piston caliper
Rear Brake	Single 240 mm disc, single-piston caliper
