Turn pneumatic-pump hose 3
toward the pneumatic pump
and close velcro fastener 2.
Sit on the motorcycle, hold it
upright and allow as much of
your weight as possible to rest
on the motorcycle.
Push in the valve pin, allow air
to escape from the Air Damp-
ing System and check the
level.
You can use the point of
the valve cap to push in the
valve pin.
Continue to allow air to escape
until the fore-and-aft tilt indicat-
or shows horizontal.
Screw the valve cap onto the
Air Damping System valve.
Remove the seat ( 41)
Install the pneumatic pump
( 34)
Damping
Adjustment for front
suspension
You can fine-tune the suspension
to the road surface by adjusting
both the compression-stage and
rebound-stage damping charac-
teristics of the telescopic forks.
The rebound-stage setting con-
trols the way the suspension re-
acts as it extends, whereas the
compression-stage setting influ-
ences compression of the front
forks under load.
The harder the setting, the more
the movement that the forks can
make to absorb surface irreg-
ularities is damped. When you
choose a soft setting the forks
respond all the more rapidly to
surface irregularities.
Adjusting rebound stage
for front wheel
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
