BMW G 650 XCOUNTRY User Manual

Remove screw 1.
Remove screws 2.
Work the side panel down to
remove.
Open cap of the expansion
tank for coolant 1.
Top up the coolant to the spe-
cified level.
Close the cap of the expansion
tank for coolant.
Seat the side panel in
mounts 3.
Install screws 2.
8
66
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
