fuse up and out of the fuse
box.
If fuse defects recur fre-
quently have the electric
circuits checked by a specialist
workshop, preferably an author-
ised BMW Motorrad dealer.
Fuse assignment
A ABS (OE) (10 A)
B Engine management control
unit (15 A)
C Low-beam headlight (7.5 A)
D Brake light, horn, instru-
ment cluster, diagnosis plug
(7.5 A)
E Side light, number-plate
light, headlight flasher, high-
beam headlight (7.5 A)
F Starter relay, flashing turn
indicators, diagnosis plug
(15 A)
G Spare fuse (15 A or 10 A
for optional extra)
H Spare fuse (7.5 A)
I Spare fuse (15 A)
Installing fuse
Remove the defective fuse and
replace it with a fuse of the
correct amperage rating.
Close the fuse cover.
The latch engages with an
audible click.
Install the seat ( 38)
Removing ABS fuse
Risk of fire if an attempt is
made to jumper defective
fuse.
Always replace defective fuses
with new fuses of the correct
amperage rating.
Switch off the ignition.
Remove the right side panel
( 90)
Check the fuse-assignment
diagram and pull the defective
fuse up and out of the fuse
box.
If fuse defects recur fre-
quently have the electric
circuits checked by a specialist
workshop, preferably an author-
ised BMW Motorrad dealer.
8
79
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
