BMW G 650 XCOUNTRY User Manual

While holding the headlight,
remove three screws 1.
Remove cover 2 and lift the
headlight out of the housing.
Disconnect plugs 3, 4 and 5.
Replacing low-beam and
high-beam headlight bulb
Remove the headlight ( 80)
Remove rubber cap 1.
Disengage spring clips 2 from
the fastenings and swing them
aside.
Pull high-beam/low-beam
bulb 3 out of the headlight
housing.
Replace the defective bulb.
Bulb for low-beam and
high-beam headlight
H4 / 12 V / 55...60 W
8
81
z Maintenance

BMW G 650 XCOUNTRY Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Max Torque	60 Nm (44 lb-ft) at 5, 250 rpm
Transmission	5-speed
Fuel System	Electronic fuel injection
Front Suspension	45 mm telescopic fork
Max Power	53 hp (39 kW) at 7, 000 rpm
Fuel Capacity	9.5 liters
Seat Height	840 mm
Front Brakes	Single 300 mm disc, 2-piston caliper
Rear Brakes	Single 240 mm disc with single-piston caliper
Dry Weight	148 kg
