Access
In the wheel house, turn the cover counter‐
clockwise and remove it.
Turn signal
24-watt bulb, PSY24W.
1.
Turn the left bulb holder counterclockwise
and remove.
2. Press the bulb gently into the socket, turn
counterclockwise and remove.
3. Install the new bulb and bulb holder in re‐
verse order of removal.
4. Attach the cover to the wheel house.
High beams
55-watt bulb, H11.
1. Turn the right bulb holder counterclock‐
wise and remove.
2. Press the bulb gently into the socket, turn
counterclockwise and remove.
3. Install the new bulb and bulb holder in re‐
verse order of removal.
4. Attach the cover to the wheel house.
Turn signal in exterior mirror
Follow general instructions, refer to page 190.
The turn signals in the exterior mirrors feature
LED technology. Contact your service center
in the event of a malfunction.
Tail lights, bulb replacement
Follow the general instructions on lamps and
bulbs, refer to page 190.
The tail lights in the tailgate feature LED tech‐
nology.
The lights in the bumper include the function
of the rear fog lamp and the reverse gear lights.
In addition, the lights in the bumper assume
the function of the tail lights if the tailgate is
opened.
Contact your service center in the event of a
malfunction.
Seite 193
Replacing components Mobility
193
Online Edition for Part no. 01 40 2 960 865 - II/15
