BMW K 1200 R User Manual

Switch off the ignition.
Check the oil level in oil-level
indicator 1.
Engine oil, specified level
Between MIN and MAX
marks
If the oil level is below the MIN
mark:
Top up the engine oil ( 100)
If the oil level is above the MAX
mark:
Drain the engine oil ( 101)
Topping up engine oil
Remove the seat ( 66)
Damage to the engine
can result if it is operated
without enough oil, but the same
also applies if the oil level is too
high.
Always make sure that the oil
level is correct.
Wipe the area around the filler
neck clean.
Remove cap of oil filler neck 1
by turning it counter-clockwise.
Top up the engine oil to the
specified level.
Check the engine oil level
( 99)
8
100
z Maintenance

BMW K 1200 R Specifications

General

Displacement	1157 cc
Power	163 hp (120 kW) at 10, 250 rpm
Transmission	6-speed
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Duolever
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Torque	127 Nm at 8, 250 rpm
Fuel Capacity	19 liters
Seat Height	820 mm
Dry Weight	217 kg
Bore x Stroke	79 mm x 59 mm
Fuel Type	Unleaded
Clutch	Wet, multi-disc
Gearbox	6-speed, constant mesh
Frame	Aluminum bridge-type frame
Rear Suspension	BMW Motorrad Paralever
Front Wheel Travel	115 mm
Rear Wheel Travel	135 mm
Front Brake	Dual 320 mm discs, 4-piston calipers
Rear Brake	Single 265 mm disc, 2-piston caliper
ABS	Optional
Maximum Speed	Over 200 km/h
