General| Compression Ratio | 12.0 : 1 |
|---|---|
| Final Drive | Shaft drive |
| Rear Brake | Single disc brake, diameter 276 mm, double-piston floating caliper |
| Displacement | 1, 170 cc |
| Max Power | 92 kW (125 hp) at 7750 rpm |
| Max Torque | 125 Nm at 6500 rpm |
| Fuel System | Electronic fuel injection |
| Transmission | 6-speed, constant mesh |
| Clutch | Wet, multi-plate, anti-hopping |
| Rear Suspension | Cast aluminum single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring preload continuously adjustable by means of handwheel, rebound-stage damping adjustable |
| Front Brake | Dual disc brake, floating brake discs, diameter 320 mm, 4-piston fixed calipers |
| ABS | BMW Motorrad ABS |
| Fuel Capacity | 18 l |
| Height (excl. mirrors) | 1225 mm |
| Seat Height | 800 mm (standard seat) |
