Installing seat
Engage seat 2 at the rear in
such a way that rests 3 are
seated on the rear trim panels.
Engage the seat at the front.
Make sure that both sides of
the seat are engaged in re-
cesses 4 of the body panels.
If too much pressure is ap-
plied in the forward direc-
tion, there is a danger that the
motorcycle will be pushed off its
stand.
Always make sure that the
motorcycle is stable and firmly
supported.
Firmly press down on the seat
at the rear.
The seat engages with an aud-
ible click.
4
61
z Operation

BMW R 1200 R Specifications

General

Compression Ratio	12.0 : 1
Final Drive	Shaft drive
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Displacement	1, 170 cc
Max Power	92 kW (125 hp) at 7750 rpm
Max Torque	125 Nm at 6500 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed, constant mesh
Clutch	Wet, multi-plate, anti-hopping
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring preload continuously adjustable by means of handwheel, rebound-stage damping adjustable
Front Brake	Dual disc brake, floating brake discs, diameter 320 mm, 4-piston fixed calipers
ABS	BMW Motorrad ABS
Fuel Capacity	18 l
Height (excl. mirrors)	1225 mm
Seat Height	800 mm (standard seat)
