BMW R 1200 R User Manual

Push release lever 2 down.
The release lever engages.
Turn the key to the LOCK pos-
ition in the case lock.
The case is closed.
Removing cases
Turn the key to the RELEASE
position in the case lock.
The handle pops out.
Pull handle 3 out and then pull
it up as far as it will go.
The case is released and can
be removed.
Installing cases
Pull the handle up as far as it
will go.
Seat the case in holders 4.
7
89
z Accessories

BMW R 1200 R Specifications

General

Compression Ratio	12.0 : 1
Final Drive	Shaft drive
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Displacement	1, 170 cc
Max Power	92 kW (125 hp) at 7750 rpm
Max Torque	125 Nm at 6500 rpm
Fuel System	Electronic fuel injection
Transmission	6-speed, constant mesh
Clutch	Wet, multi-plate, anti-hopping
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring preload continuously adjustable by means of handwheel, rebound-stage damping adjustable
Front Brake	Dual disc brake, floating brake discs, diameter 320 mm, 4-piston fixed calipers
ABS	BMW Motorrad ABS
Fuel Capacity	18 l
Height (excl. mirrors)	1225 mm
Seat Height	800 mm (standard seat)
