Fit the bulb 3 in the bulb
holder.
Insert the bulb holder into the
headlight housing and turn
lever 2 clockwise to latch it in
position.
Installing flashing turn indicator
with fairing panel ( 117).
Replacing brake-light,
rear-light and rear-
indicator bulbs
If it is not standing firmly,
the motorcycle could topple
in the course of the operations
described below.
Always make sure that the
motorcycle is stable and firmly
supported.
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Switch off the ignition.
If applicable, remove the cases.
Remove screws 1 on left and
right and work the bulb hous-
ing to the rear to remove.
Turn bulb holders 2 for the
indicator bulbs or bulb hold-
ers 3 for the brake-light/rear-
light bulbs counter-clockwise
8
113
z
Maintenance
