BMW R 1200GS Adventure 2015 User Manual

Detach lid retaining cable 1.
Close case lid.
Open second latch of case lid.
Remove case lid.
Install case lid
with aluminum case
OA
Lay case lid on case.
Close one lock of case lid.
Open case lid toward closed
side.
Hook in lid retaining cable 1.
Close case lid.
Close second lock of case lid.
Remove case
with aluminum case
OA
Turn key 1 counterclockwise.
Press lock housing 2 to side to
release locking claw 3.
Pull locking claw 3 to side
while holding case in place.
Pull case forward as far as pos-
sible and remove to side.
Mount case
with aluminum case
OA
8
149
z Accessories
ProCarManuals.com

BMW R 1200GS Adventure 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Weight, Wet	260 kg
Engine Type	Air/liquid-cooled four stroke flat twin engine
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston calipers
Rear Brake	Single disc brake
Length	2255 mm
Seat Height	890 / 910 mm (Optional low seat: 860 / 880 mm)
Fuel Capacity	30 liters
