BMW R 1200GS Adventure 2015 User Manual

Turn key 1 counterclockwise.
Press lock housing 2 upward
to release locking claw 3.
Pull locking claw 3 toward rear
and open lid.
Close topcase
with aluminum Topcase
OA
Close topcase lid.
Position locking claw 1 on lid.
Press lock housing 2 down-
ward while making sure that
claw grips into lid.
To lock lock, turn key 3 clock-
wise and remove.
Remove topcase
with aluminum Topcase
OA
Turn key 1 counterclockwise.
Press lock housing 2 down-
ward to release locking claw 3.
Pull locking claw 3 back.
First pull topcase toward rear
and then remove upward.
Mounting topcase
with aluminum Topcase
OA
8
151
z Accessories
ProCarManuals.com

BMW R 1200GS Adventure 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Weight, Wet	260 kg
Engine Type	Air/liquid-cooled four stroke flat twin engine
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston calipers
Rear Brake	Single disc brake
Length	2255 mm
Seat Height	890 / 910 mm (Optional low seat: 860 / 880 mm)
Fuel Capacity	30 liters
