BMW R 1200GS Adventure 2015 User Manual

In order to remove the front
height adjustment 1, press
locking mechanism 2 down to
remove the height adjustment
upwards.
In order to adjust the low seat
position, install the front height
adjustment in orientation 1 (L
marking).
In order to adjust the high seat
position, install the front height
adjustment in orientation 2 (H
marking).
First, slide the front height
adjustment under mounts 1.
Then press locking mecha-
nism 2, until it engages.
In order to adjust the low seat
position, swivel rear height ad-
justment 1 into position 3 (L
marking).
In order to adjust the high seat
position, swivel rear height ad-
justment 1 into position 2 (H
marking).
If seat tilt should be changed:
Position the front and rear
height adjustment differently.
Install rider's seat ( 80).
4
81
z Operation
ProCarManuals.com

BMW R 1200GS Adventure 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Weight, Wet	260 kg
Engine Type	Air/liquid-cooled four stroke flat twin engine
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston calipers
Rear Brake	Single disc brake
Length	2255 mm
Seat Height	890 / 910 mm (Optional low seat: 860 / 880 mm)
Fuel Capacity	30 liters
